EMTELLE 144F Mini Cable G652D 200u Black (5.4mm) 4000m

75427/4KM

This cable features a stranded core with a central FRP strength member and gel-filled loose tubes containing optical fibers. The core is secured with water-swellable yarns, while the outer sheath is made of black polyamide PA12. It includes 144 optical fibers arranged in six loose tubes, each holding 24 fibers. The cable has a diameter of 5.4 mm, with a 0.4 mm thick outer sheath, and extends 4000 meters. It uses Corning SMF 28®ULTRA and SMF 28+®BB fibers compliant with ITU-T G.652D and G.657.A1 standards, ensuring precise dimensional specifications for optimal performance.

Data Sheet Click To Open.
