EMTELLE 48F Mini Cable G657A1 Black (5.8mm) 4000m

90409/4KM

The 48F Mini Cable G657A1 Black (5.8mm) is engineered for efficient installation via microduct blowing. It features a 5.8mm diameter and weighs 25.2g per meter, with a black, metal-free HDPE outer sheath. The cable includes 48 single-mode G657A1 fibers arranged in four gel-filled loose tubes, reinforced by a 1.6mm fiberglass strength member and an SZ-stranded core. It supports a minimum bend radius of 19 times its diameter and withstands installation tensions up to 475N with minimal fiber strain. Supplied on a 4000m wooden G drum, this cable meets ITU-T G.657.A1 standards for reliable performance.

Data Sheet Click To Open.
