Mills 80T Optical Power Meter

C00-6434

The Mills Optical Power Meter is a durable, affordable, and high-resolution handheld device designed for comprehensive optical testing on both single-mode and multi-mode fibers. It supports six wavelengths—850, 1000, 1310, 1490, 1550, and 1625 nm—with a dynamic range spanning +10 to -70 dBm. The meter includes a cordura-style pouch and comes equipped with universal 2.5mm, ST, FC, and screw-on LC adapters. Powered by 2 AA batteries (not included), it features an auto power-off function, compatibility with PC and APC connectors, and offers up to 100 hours of battery life. Dimensions are 105 x 52 x 34 mm, weighing 100 g.

Data Sheet Click To Open.
